The HandySCAN 700 is Creaform’s flagship metrology-grade portable 3D scanner. The HandySCAN 3D product line underwent a complete re-engineering in 2014. Creaform HandySCAN 3D handheld 3D scanners won the Red Dot Award for Product Design 2015. The Red Dot is awarded for international product design, communication design, and design concept. This HandySCAN 700 metrology handheld 3D scanners have been optimized to meet the needs of product development and engineering professionals. The HandySCAN 3D is capable of quickly delivering accurate and high-resolution 3D scans.
The Creaform’s HandySCAN 3D is available in two versions:
  • HandySCAN 300, the most affordable version of the lineup. It offers accuracy up to 0.040 mm (0.0016 in.), a maximum resolution of 0.100 mm (0.0039 in.). Its top acquisition rate is 205,000 measurements/s, within a 3D scanning area of 225 x 250 mm (8.8 x 9.8 in.).
  • HandySCAN 700 is the flagship 3D scanner of the HandySCAN family. It offers accuracy up to 0.030 mm (0.0012 in.) and a maximum resolution of 0.050 mm (0.0020 in.). Its top acquisition rate is 480,000 measurements/s, within a 3D scanning area of 275 x 250 mm (10.8 x 9.8 in.).

Both HandySCAN 300 and HandySCAN 700 provide ground-breaking accuracy, resolution and substantially higher measurement rates—all in truly portable device. The benefits of the metrology-grade HandySCAN 3D’s are truly compelling:

  • 40% more accurate with a volumetric accuracy of 60µm/m.
  • 25 times faster than former generation.
  • TRUaccuracy feature ensures accurate measurements in real life operating conditions
  • Unmatched versatility: Limitless 3D scanning possibilities, regardless of the part size, complexity, material, or color.
  • Quick set-up: Get up and running in less than 2 minutes.
  • Automatic mesh output: Get ready-to-use files as soon as data acquisition is complete—and integrate within your workflow without any post-processing.


  • Aerospace
  • Industry
  • Consumer goods manufacturing
  • Evaluation of Pipeline Integrity
  • Automotive Repair
  • Education & Science


  • 25 times faster than the previous generation
  • 40% more accurate
  • Improved ergonomy: 35% lighter, 50% smaller, Greater freedom of movement, Multi-function buttons for easier interaction with the software


  • Metrology-grade measurements: accuracy of up to 0.030 mm (0.0012 in.), resolution of up to 0.050 mm (0.002 in.), high repeatability and traceable certificate.
  • Accuracy in real-life conditions: regardless of environment conditions, part set-up or user.
  • No rigid setup required: optical reflectors are used to create a reference system that is “locked” to the part itself, so users can move the object any way they want during scanning sessions (dynamic referencing). Changes in surrounding environment have no impact on data acquisition quality or accuracy.
  • Self-positioning: the HandySCAN 3D scanner is a data acquisition system and its own positioning system. This means that no external tracking or positioning devices is required. It uses triangulation to determine its relative position to the part in real time.
  • Reliable: consistent and repeatable results across all work conditions or environments.
  • On-demand user calibration: the scanner can be calibrated as often as necessary (day-to-day basis or before each new scanning session).
  • Calibration takes about 2 minutes and guarantees optimal operation.


  • Stand-alone device: there is no need for an external positioning system, arms, tripod or fixture.
  • On-the-go scanning: you can take it from place to place or use it in-house or on site.
  • Lightweight: weights under 1 kg.
  • Small: Fits into a case the size of a carry-on.
  • Easy access to confined spaces: thanks to its small size and flexible stand-off distance.


  • Fastest 3D scanner on the market: 25 times faster than the previous generation.
  • Highest measurement rate among all laser scanners: 480,000 measures/s.
  • Automatic mesh output: ready-to-use files, right as you complete acquisition.
  • Quick workflow integration: usable scan files can be imported into RE/CAD software without post-processing.


  • User-friendly: very short learning curve, regardless of the user’s experience level.
  • Quick set-up: up and running in less than 2 minutes.
  • Direct mesh output: no complicated alignment or point cloud processing.
  • Real-time visualization: look at the computer screen to see what you are doing and what is left to be done.
  • Versatile: virtually limitless 3D scanning – no matter the part size, complexity, material or color.
  • Availability: In Stock
  • Brand: Creaform
